CMV-G High Voltage Stationary Solid Soft Starter

★  CMV-G's manifolds module is fixed in the cabinet and cannot be pulled out.

Model:CMV-G_Fixed manifolds

Supply Voltage:AC 3 ~ 10 kV

Applicable motor:3-Phase High Voltage Squirrel-Cage Asynchronous and Synchronous Motors

Motor Power:400 ~ 14000 kW

Application:Suitable for water pumps, fans, compressors, pulverizers, mixers, belt conveyors and other mechanical and electrical equipment.

Download:CMV High-voltage Soft Starter User Manual V1.0.pdf

Features of CMV-G solid-state Motor Soft Starts Device

• The thyristor valve body is used as the main circuit component. Advanced technology, reliable work, modular structure, maintenance-free.

• Strong adaptability, able to work normally under the condition of isolated grid or generator set at home and abroad.

• Central control is performed based on 32-bit ARM core microcontroller. Fast response, high control precision and strong anti-interference ability.

• The cabinet adopts KYN28 structure, with beautiful appearance. The material is made of aluminum-zinc plate, which is assembled by multiple bending. All control operations are performed with the cabinet door closed.

• Separation of high and low voltage, the cabinet is composed of three parts: low-voltage chamber, high-voltage chamber and manifolds chamber, with five anti-locking functions.

• The cabinet is the same as the standard switchgear, and can be easily combined with other high-voltage switchgear on site, making the whole system style uniform and beautiful.

• Protection class: IP40.

★ The manifolds module is fixed in the cabinet and cannot be pulled out.

Technical Parameters of CMV-G High Voltage Stationary Solid Soft Starter

Model Selection of CMV-G High Voltage Stationary Solid Soft Starter

Note:

1. The above are typical product models, if the model you need is not in this table, please contact us.

2. The above cabinet dimensions are for reference, we provide non-standard customized products.

3. The grid-side contactor is an optional accessory. If you need to add a grid-side contactor, please specify when ordering.

Industrial application of CMV-G High Voltage Stationary Solid Soft Starter

Widely used in electric power, metallurgy, petrochemical, building materials, thermal power, papermaking, water conservancy, environmental protection, mining machinery and other industries.

How to order high-voltage motor soft start device

Please provide the following information when ordering:

• Topside power supply condition.

• Motor model, rated power, rated voltage, rated current, rated speed.

• Motor drag load type (fan, water pump, etc.).

• In and out wiring of equipment.

• Installation position condition, cabinet color.

• Equipment usage environment.

Customers in plateau, high altitude (>2000m), high cold (<-15℃), high temperature (>+50℃), serious pollution by salt spray, and high humidity areas, please explain in advance

Note: If you have other special requirements (such as increasing the protection level), please contact us.
